Difference Between And 2032 Battery
Two coin cells can look identical but behave very differently. The spec that matters most is thickness, because it decides fit and roughly how much energy the cell can hold. A common mistake is swapping batteries by diameter alone and causing poor contact or short runtime. First check the battery code printed on the device or in the manual.
Difference between 2016 and 2032 battery is thickness and capacity: 2016 is 1.6 mm thick, 2032 is 3.2 mm; both are 20 mm diameter, 3 V lithium coin cells, and the 2032 usually stores roughly two times the energy of the 2016.
Specs: 2016 vs 2032
CR2016 and CR2032 share the same 20.0 millimeter diameter and the same nominal chemistry family, but CR2032 is 3.2 mm thick versus 1.6 mm for CR2016, giving the 2032 substantially more stored energy. The thickness is the physical compatibility limiter, and swapping sizes requires checking device battery well depth and voltage expectations, especially if a rechargeable LIR variant is offered.
| Spec | CR2016 | CR2032 |
|---|---|---|
| Diameter | 20.0 mm | 20.0 mm |
| Thickness | 1.6 mm | 3.2 mm |
| Nominal voltage | 3.0 V (lithium manganese dioxide) | 3.0 V (lithium manganese dioxide) |
| Typical capacity (manufacturer varies) | Lower, single-digit to low hundreds of mAh range | Higher, typically two to three times the 2016 |
| Common markings | CR2016, sometimes date or lot code; LIR2016 for rechargeable | CR2032, LIR2032 for rechargeable coin cells |
| Common uses | Thin watches, slim remotes, small sensors | Key fobs, CMOS motherboard backup, larger remotes, sensors |
Manufacturers report capacity in milliamp-hours, but the number depends on test current, cutoff voltage, and temperature. Compare datasheet test conditions because a “typical” mAh figure may be measured at a light continuous drain, while real-world pulse loads and higher drain rates reduce usable capacity.
CR indicates a nonrechargeable lithium manganese dioxide coin cell with nominal 3 V. LIR prefixed cells are rechargeable lithium-ion coins and can have different nominal voltages and charging requirements. Do not attempt to charge CR cells, and verify device support before substituting LIR variants because voltage and charging needs differ.
Size is usually the deciding factor: if a device only fits 1.6 mm thickness, a 2032 will not fit even though diameter matches. If the well accepts 3.2 mm, the 2032 will give longer run time at the same voltage, but check contacts and spring tension for reliable connection.
Capacity and Runtime
The CR2032 holds roughly twice the stored energy of a CR2016 because both share the same 20 millimeter diameter and the 2032 is about twice as thick, so its active volume is about double. Convert milliamp-hours to watt-hours with Wh = (mAh / 1000) × nominal voltage, usually 3 volts for these lithium coin cells, to compare usable energy between sizes.
mAh is a charge capacity number, Wh is real energy. Use Wh when you want to compare how long a device running at a given wattage will actually run from a cell rated at a given mAh and voltage.
For example, using common representative capacities (not every part is the same): treat CR2016 ≈ 90 mAh and CR2032 ≈ 200 mAh at 3 V. That converts to about 0.27 Wh and 0.6 Wh respectively, so the 2032 supplies a bit more than double the energy.
| Assumed continuous draw | 2016 runtime (90 mAh) | 2032 runtime (200 mAh) |
|---|---|---|
| 1 microamp (0.001 mA), very low-drain sensor | ~10 years | ~23 years |
| 0.1 mA, low-power keyfob/sensor average | ~37 days | ~83 days |
| 1 mA, moderate continuous drain | ~3.8 days | ~8.3 days |
Discharge rate changes effective capacity, because higher current increases voltage sag across internal resistance and can reduce usable mAh. Pulsed loads can be efficient if idle current is tiny, but frequent high-current bursts shorten run time more than steady low current at the same average.
Temperature also affects usable capacity, cold reduces chemical reaction rates and available voltage, often cutting capacity by tens of percent at low temperatures for lithium coin cells. If your device must run in cold environments, prefer the thicker cell or check manufacturer guidance.
Charging & Compatibility
2016 and 2032 name the same 20 mm diameter coin cell with different thickness, 1.6 mm versus 3.2 mm, and both sizes are sold as non-rechargeable CR and as rechargeable LIR types. Never attempt to charge a CR cell, and only use chargers explicitly rated for the rechargeable LIR chemistry and size you have.
| Attribute | 2016 | 2032 | Compatibility / Charging notes |
|---|---|---|---|
| Diameter | 20 mm | 20 mm | Same diameter, will contact the same spring/holder if thickness is compatible |
| Thickness | 1.6 mm | 3.2 mm | 2032 is thicker; may not fit low-profile holders or cases |
| Typical chemistry labels | CR2016 (primary) or LIR2016 (rechargeable) | CR2032 (primary) or LIR2032 (rechargeable) | Check exact cell code on label before replacing or charging |
| Nominal voltage | CR: about 3.0 V, LIR: ~3.6-3.7 V | CR: about 3.0 V, LIR: ~3.6-3.7 V | Replacing CR with LIR changes voltage, which can upset electronics |
| Recharge & charger | Only LIR versions can be charged, charger must list LIR or Li-ion coin cells | Only LIR versions can be charged, charger must list LIR or Li-ion coin cells | Verify charger voltage, chemistry setting, and charge termination method |
Do not charge CR cells. If you find a CR2016 or CR2032 in a device that appears to be rechargeable, remove the cell and check the manual or PCB markings. If the device tries to recharge a non-rechargeable cell, the cell can leak, vent, or rupture.
For example, replacing a CR2032 in a computer motherboard with an LIR2032 can raise the backup-battery voltage from about 3.0 V to about 3.6 V, causing the board to misread the battery or stress low-voltage components, so only use LIR replacements if the manual approves them.
Safety note: never place a CR cell in a charger, and do not assume physical fit equals electrical compatibility. Verify chemistry, voltage, and charger ratings first.
Safety, Heat, Swelling
2016 and 2032 coin cells are the same diameter but the 2032 is thicker and holds more stored energy, which changes how each fails and how dangerous that failure can be. The thinner 2016 will reach high temperature faster with less total heat energy available, while the thicker 2032 can deliver more energy into a short and therefore can cause more severe heating, prolonged venting, or larger chemical leakage.
Common failure modes include an external short across the terminals, internal short from manufacturing defects or puncture, slow leakage from seal corrosion, or thermal events when the cell is forced to discharge rapidly. A short or thermal event can cause the case to heat, rupture, vent gas, or produce corrosive electrolyte, and these outcomes scale with the cell’s stored energy.
Recognize swelling, bulging, or case deformation as immediate replacement triggers, regardless of size. Other triggers are excessive heat during normal use, visible corrosion at the terminals, a battery that gets warm while idle, or devices that refuse to power on despite correct polarity. If any of these signs appear, remove the battery safely and replace it with the correct type.
Device Examples and Fit
CR2016 cells are 20 millimeters across and about 1.6 millimeters thick, while CR2032 cells share the 20 millimeter diameter but are about 3.2 millimeters thick, both typically 3 volt lithium coin cells. The thickness difference is the practical limit for swapping one for the other, because CR2032 usually holds roughly twice the charge but needs more axial space in the holder.
| Item | CR2016 (thin) | CR2032 (thicker) | Notes on substitution and fit |
|---|---|---|---|
| Typical devices | Slim TV remotes, compact key fobs, slim fitness trackers, some slim calculators | Motherboard CMOS/BIOS backup, larger car remotes, many wristwatches, LED keychain lights | Physical depth in the battery well is the deciding factor, not voltage. Check holder depth and contact design. |
| Why used | Low profile where thickness is constrained | Higher capacity for longer life or higher drain | Thicker cell gives longer life but can break contact in low-profile holders. |
| Polarity & orientation | Same polarity as 2032 (flat + face up in most designs) | Same polarity, same diameter, different stack height | Always confirm + and – markings; reversing will damage electronics. |
| Common replacement rule | Replace with same size when available | Can replace 2016 only if holder and spring allow extra 1.6 mm | Never force a thicker cell into a tight well. |
For many low-profile gadgets the correct choice is CR2016 because it fits without touching the battery cover or bending the spring contact. For devices where depth is available and longevity matters, CR2032 is the better choice because it lasts longer under the same load.
Safety warning: do not force a thicker cell into an undersized compartment, and do not mix cell chemistries or partially used cells. When in doubt, buy the specified size or a manufacturer-approved replacement – fit and reliable contact are more important than small capacity gains.
Buying Checks & Troubleshooting
2016 and 2032 are the same diameter coin lithium cells, but 2032 is thicker and therefore stores more energy and runs longer under the same load; both are nominally 3 volts and share the CR/BR chemistry family. Substituting a 2032 for a 2016 will only work when the battery well and contact springs have space, and mixing them can cause intermittent contact or early failure.
For example, if a small remote resets only occasionally and a new CR2032 measures 3.0 V but the problem persists, clean and retension the contacts before replacing the board. That step avoids unnecessary battery swaps and addresses the common root cause of intermittent failures.
Tech Advances and Impact
CR2016 is a 20 millimeter diameter, 1.6 millimeter thick primary lithium coin cell and CR2032 is the same diameter with 3.2 millimeter thickness and the same nominal 3 volt chemistry, but the CR2032 stores substantially more energy and usually delivers longer runtime under the same load. Because the 2032 is thicker it fits into fewer thin holders, so you must verify mechanical clearance before substituting even though the voltage matches.
| Attribute | CR2016 | CR2032 |
|---|---|---|
| Physical size | 20 mm diameter, 1.6 mm thick | 20 mm diameter, 3.2 mm thick |
| Chemistry / Voltage | Primary lithium (CR family), nominal 3 V | Primary lithium (CR family), nominal 3 V |
| Relative capacity | Lower, designed for thin, low-drain applications | Higher, typically about twice the energy under similar conditions |
| Typical uses | Very slim key fobs, small sensors, some calculators | Key fobs, watches, fitness devices, PC motherboards |
| Swap considerations | May be loose in holders made for 2032, check contact pressure | May not fit devices designed only for 2016 thin profile |
| Charging | Do not recharge, primary cell | Do not recharge, primary cell |
Material and manufacturing changes since earlier models are incremental: better electrode cleanliness, finer control of electrolyte and separator, and improved sealing reduce self-discharge and failure rates by modest amounts. These improvements change shelf life and consistency, but they do not convert a CR2016 into a higher-capacity cell or make sizes interchangeable.
Environmental impact is small per cell but significant in volume, because coin cells contain lithium and metal oxides that should not go to landfill. For safety and recycling, tape terminals on used cells to prevent short circuits, take them to municipal battery collection points or retailer take-back programs, and never incinerate or crush cells.
Regulatory and standards to check include UN 38.3 transport testing for lithium cells and the IEC 60086 series for primary battery specifications, plus local RoHS and waste directives for disposal. Manufacturer datasheets remain the authoritative source for capacity at specified discharge rates, operating temperature range, and expected shelf life.
For technical references and authoritative quotes, consult coin-cell datasheets from Renata, Panasonic/Sanyo, Sony, Energizer, and Varta, and the IEC and UN documents named above; if you need exact runtimes or flight/transport rules, verify with the device manufacturer and your local hazardous-waste authority because published standards and rules can change.
Quick Summary
The primary differences between 2016 and 2032 batteries lie in their chemistry, voltage, capacity, and intended applications.
Frequently Asked Questions
What is the main difference in compatibility between 2016 and 2032 batteries?
The 2016 battery is typically used in smaller devices like watches and remote controls, while the 2032 battery is more common in larger devices like calculators and fitness trackers. Always check the device manual for specific battery type recommendations.
Do 2016 and 2032 batteries generate different levels of heat during use?
Both batteries can generate heat, but the 2032 battery may run cooler due to lower current draw in devices that require less power. Always monitor for excessive heat, as it can indicate a problem.
How does the runtime differ between 2016 and 2032 batteries?
The 2032 battery typically has a higher capacity of around 220 mAh compared to the 2016’s capacity of about 150 mAh, leading to longer runtimes in compatible devices. However, actual runtime can vary based on device usage.
Are there safety concerns when using a 2016 battery instead of a 2032 battery?
Using a 2016 battery in place of a 2032 battery can pose safety risks, as the device may not function correctly or could overheat. Always use the manufacturer-recommended battery type to ensure safety.
What common mistakes should I avoid when replacing 2016 or 2032 batteries?
A common mistake is assuming all batteries are interchangeable; always double-check the battery size and type before purchasing. Additionally, avoid buying batteries that are past their expiration date to ensure optimal performance.
